The guide will give you answers on how to ensure the correct size of your barcodes.

How big should the EAN-13 and EAN-8 be?

The guidelines for the sizes of EAN barcodes help to ensure optimal scanning at the exit boxes. Barcode dimensions are based on a normal size, denoted by a size factor of 1.0 (100%). The following table indicates symbol dimensions for the EAN-13 and EAN-8.

NOTE: Length indications include light zone. The height indications are the short strokes above the digits, and not the long ones on the sides.

‍

Light Zone

There should be a free area to the left and to the right of the barcode symbol - this area is called the light zone.

Light zone size for EAN-13 barcodes:

Left light zone = 11 x the module width (X in the diagram below)
Right light zone = 7 x the module width (X in the diagram below)

The size of the light zone for EAN-8 barcodes: ‍

Left light zone = 7 x the module width (X in the diagram below)
Right light zone = 7 x the module width (X in the diagram below)

Altitude reduction

As far as possible, you should avoid height-reducing the barcode. Height reduction of barcodes should be made only if absolutely required. When the height of the barcode symbol is reduced, scanning the barcode can become more cumbersome.

‍

Sizes of EAN-13 and EAN-8

Note: The height is without the numbers below the barcode

‍

‍
